BotOnly STC-PS-117 Heavy Counterbalance Pallet Stacker
A heavy counterbalance pallet stacker for high-load pallet storage and transfer, with a 3,500 kg payload and 3,000 mm lift.
- Model
- STC-PS-117
- Product type
- Heavy Counterbalance Pallet Stacker
At a glance
Key Specifications
Manufacturer-rated specifications
- Rated payload
- 3,500 kg
- Dimensions
- 3,495 × 1,380 × 2,461 mm
- Lift height
- 3,000 mm
- Travel speed (loaded/unloaded)
- 5/6 km/h
- Runtime
- 4–6 h
- Positioning accuracy
- ± 10 mm
- Battery
- 80 V / 420 Ah
- Vehicle weight
- 5,450 kg
Technical data
Detailed Specifications
Manufacturer-rated specifications
- Rated payload
- 3,500 kg
- Dimensions
- 3,495 × 1,380 × 2,461 mm
- Vehicle weight
- 5,450 kg
- Lift height
- 3,000 mm
- Travel speed (loaded/unloaded)
- 5/6 km/h
- Runtime
- 4–6 h
- Positioning accuracy
- ± 10 mm
- Battery
- 80 V / 420 Ah
- Charging time (manual/automatic as supplied)
- 2.1/4.2 h
- Minimum stacking aisle
- 3,860 mm
Description & advantages
This product is designed to operate as part of a coordinated storage and production-material workflow rather than an isolated vehicle.
- Rapid mapping and route adjustment for changing production layouts
- AIDT digital-twin monitoring and fault-warning support
- Multi-sensor protection for mixed human and robot operating areas
Key features
Heavy-duty counterbalance stacking
- Heavy-duty counterbalance stacking
Applications & cases
Where this product fits
- Heavy pallet putaway and retrieval
- High-load warehouse transfer
- Industrial production logistics
Configuration note
Pricing depends on the selected configuration. Your quote will itemize the machine, options, freight, installation and commissioning separately.
