BotOnly STC-PS-116 Counterbalance Pallet Stacker
A counterbalance pallet stacker for automated pallet storage and transfer, with a 2,000 kg payload and 2,500 mm lift height.
- Model
- STC-PS-116
- Product type
- Counterbalance Pallet Stacker
At a glance
Key Specifications
Manufacturer-rated specifications
- Rated payload
- 2,000 kg
- Dimensions (L×W×H)
- 2,923 × 1,116 × 2,326 mm
- Lift height
- 2,500 mm
- Travel speed (loaded/unloaded)
- 5/6 km/h
- Runtime
- 6–8 h
- Positioning accuracy
- ± 10 mm
Technical data
Detailed Specifications
Manufacturer-rated specifications
- Dimensions (L×W×H)
- 2,923 × 1,116 × 2,326 mm
- Rated payload
- 2,000 kg
- Lift height
- 2,500 mm
- Minimum stacking aisle
- 4,080 mm
- Travel speed (loaded/unloaded)
- 5/6 km/h
- Positioning accuracy
- ± 10 mm
- Battery
- 24 V / 200 Ah
- Runtime
- 6–8 h
- Charging time (manual/automatic)
- 4/2 h
- Vehicle weight
- 3,300 kg
Description & advantages
This product is designed to operate as part of a coordinated storage and production-material workflow rather than an isolated vehicle.
- Rapid mapping and route adjustment for changing production layouts
- AIDT digital-twin monitoring and fault-warning support
- Multi-sensor protection for mixed human and robot operating areas
Key features
High-load stacking with automated rack interface
- Counterbalance pallet stacking
- High-load automated rack interface
Applications & cases
Where this product fits
- Pallet putaway and retrieval
- Warehouse rack handling
- Production-line transfer
Configuration note
Pricing depends on the selected configuration. Your quote will itemize the machine, options, freight, installation and commissioning separately.
Not sure this is the right machine?
Tell us what needs to move and where. If a different category — or a different supplier — fits your site better, we'll say so.
Request a Quote
Discuss your application with our team to get a configuration and pricing plan tailored to your site.
