BotOnly FLT-CB-109 Counterbalanced Forklift
The BotOnly FLT-CB-109 is an autonomous counterbalanced forklift for pallet transport and stacking between warehouse, production and equipment-docking locations. It has a rated load of 2,000 kg and a maximum lift height of 4,500 mm, with a load capacity of 800 kg at that height. LiDAR navigation is standard, with reflector positioning available as an option.
- Model
- FLT-CB-109
- Product type
- Counterbalanced Forklift
At a glance
Key Specifications
- Rated Load
- 2,000 kg
- Maximum Lift Height
- Up to 4,500 mm
- Turning Radius
- 1,800 mm
- Positioning Accuracy
- ± 10 mm
- Navigation
- LiDAR standard; reflector navigation optional
- Load Capacity at Maximum Lift Height
- 800 kg
Technical data
Detailed Specifications
- Rated Load
- 2,000 kg
- Maximum Lift Height
- Up to 4,500 mm
- Turning Radius
- 1,800 mm
- Travel Speed
- 1.38–1.5 m/s
- Positioning Accuracy
- ± 10 mm
- Navigation
- LiDAR standard; reflector navigation optional
- Battery
- Lithium iron phosphate, 200 Ah
- Runtime / Charging
- 6–8 hours; automatic or manual charging
- Load Capacity at Maximum Lift Height
- 800 kg
Key features
Autonomous pallet transport and stacking
- Autonomous pallet transport and stacking
- LiDAR navigation with optional reflector positioning
- Pallet pose recognition and goods presence detection
- Bottom obstacle radar and stereo obstacle avoidance
- Fork-tip collision detection and emergency stop functions
Applications & cases
Where this product fits
- Two-way or four-way pallet transfer
- Production-line and equipment docking
- Horizontal warehouse transport
- Pallet stacking and high-level storage within the verified lift configuration
Configuration note
Final quotation depends on top module, navigation and safety configuration, fleet/software integration, quantity, freight, installation and commissioning.
